Novel Cost Effective Surficial Geometric Imperfection Measurement Device

The developed technology provides a cost-effective, portable, and non-contact laser-based solution for accurate quantification of surficial geometric imperfections in structural and construction materials. By enabling high-precision imperfection measurement, the system supports realistic structural performance assessment, improved quality control, expedited manufacturing, and compliance with international engineering and quality standards.

The technology is applied for precise measurement and characterization of local geometric imperfections in building and engineering materials such as cold-formed light gauge steel sections, bamboo culms, and 3D concrete printed surfaces. The measured imperfection data can be directly incorporated into numerical modelling and structural analysis, facilitating material grading, quality assurance, realistic prediction of failure modes, and development of improved structural design methodologies.

• Non-contact laser-based measurement ensuring high accuracy
• Portable and cost-effective compared to conventional surface inspection systems
• Applicable to a wide range of materials and surface geometries
• Adjustable scanning speed for different material types
• Enables realistic structural modelling and improved design reliability
• Reduces inspection time, rework, and manufacturing defects
• User-friendly operation requiring minimal skilled manpower
